(1) Patented “Lock & Unlock System” - To lock and unlock the bag insertion area, allowing
for the packing cycle to be executed in automatic mode and freeing the operator for other
activities. The Lock & Unlock System is controlled by two Handles (1), which rotate in three
predefined positions to open (OPEN) - close (STORAGE) and activate the machine (START).
(2) Control panel - To set the various functions of the machine (see paragraph: DESCRIPTION OF
CONTROLS AND FUNCTIONS).
(3) Lit Window - Patented solution that allows the user to see the correct positioning of the bag
in the vacuum Chamber.
(4) Air intake for the Tube (ACCESSORY PORT) - To insert the Tube to perform vacuum packing
in all canisters and with all MAGIC VAC
®
accessories.
(5) Cover - Open in the upper fixed position, it allows for bags to be positioned before proceeding
with packing.
(6)
Sealing bar - Heating element which seals the bag.
(7)
Airtight gasket
- Guarantees the vacuum in the chamber allowing for air to be evacuated from
the bags MAGIC VAC
®
.
(8) Vacuum chamber - Is the location for positioning the bag and evacuating the air.
(9)
Sealing gasket - Presses the bag on the Sealing Bar.
(10) Removable Tray - Patented solution that allows the Vacuum Chamber to be washed in the
dishwasher for maximum hygiene.
(11)
Roll-Holder Compartment
(12)
Roll-Holder Compartment Cover
- It protects the roll from possible soiling during the packing
phases.
(13)
Bag Cutter
- Can be used in both directions.
(14) Anti-skid Feet - Prevent the machine from sliding during use.
(15)
Accessory Compartment
- Compartment for storing the Magic Cutter (19) (where applicable)
and the Canister Connection Tube, located on the lower part of the machine.
(16) Canister Tube - This connects the machine to all of the MAGIC VAC
®
accessories.
(17) Power Cable - To connect the machine to power.
(18)
Cable Compartment - Compartment for storing the Power Cable, located on the back of the
machine.
MACHINE PART NAMES
25
