MagMate 180P
Part No. MAG180P
Input Power (V) 240 ± 15% Single Phase
Frequency (Hz) 50 / 60
Rated input current (A) 20.3
Output current adjustment (A) 50–180
Output voltage adjustment (V) 14–26
Duty Cycle (%) 60
Power Factor 0.73
Efficiency (%) 80
Type of wirefeeder machine Compact
Wire speed (m / min) 2–15
Post flow (s) 1
Maximum spool size (mm) 200
Wire diameter (mm) 0.6/0.8/0.9
Housing shielding grade IP21
Insulation grade F
Suitable thickness (mm) Above 0.6
Weight (kg) 20
Dimensions (mm) 482 x 197 x 466
6.0 Machine Specifications
