MAGNABEND 650E - Bending Capability and Clampbar Details

7
BENDING CAPABILITY
(When using a standard full-length clamp-bar to bend a full-length work-
piece)
* With extension bar fitted to bending beam.
SHORT CLAMP-BAR SET
Lengths: Model 650E: 25, 38, 52, 70, 140, 280 mm
Models 1000E & 1250E: 25, 38, 52, 70, 140, 280, 597 mm
All sizes (except 597 mm) may be plugged together to form a bending edge
within 25 mm of any desired length up to 575 mm.
SLOTTED CLAMPBAR
When supplied, a special set of 8 mm wide slots provide for forming all tray
sizes in the range shown below:
* For deeper trays use the Short Clamp -bar set.
... SPECIFICATIONS ...
MODEL
TRAY LENGTHS MAX. TRAY DEPTH
650E 15 to 635 mm 40 mm*
1000E 15 to 1015 mm 40 mm*
1250E 15 to 1265 mm 40 mm*
MATERIAL THICKNESS LIP WIDTH BEND RADIUS
(yield/ultimate) (minimum) (typical)
Mild-steel 1.6 mm 30 mm* 3.5 mm
(250/320 MPa)
1.2 mm 15 mm 2.2 mm
1.0 mm 10 mm 1.5 mm
Aluminium 1.6 mm 30 mm* 1.8 mm
Grade 5005 H34
1.2 mm 15 mm 1.2 mm
(140/160 MPa)
1.0 mm 10 mm 1.0 mm
Stainless Steel 1.0 mm 30 mm* 3.5 mm
Grades 304, 316
0.9 mm 15 mm 3.0 mm
(210/600 MPa)
0.8 mm 10 mm 1.8 mm
