MAGNAMED Ventilator Analyzer - VentMeter P/N: 1901509 – Rev 05
It allows a galvanic cell connection to measure O
2
concentration in the respiratory circuit.
Caution
• Use only cables and sensors specified and acquired from MAGNAMED. Acquisition and part
number information see chapter 12.
8 Distal Flow Sensor Connector
Distal flow sensor pressure measurement port connector.
Caution
• Connect the tubing according to the picture shown in the front panel of the VentMeter.
9 Proximal Flow Sensor Connector
Proximal flow sensor pressure measurement port connector.
10 PC Serial RS-232 connectors
PC Serial communication connector (RS-232). It communicates exclusively to Magnamed’s PulmoTrend
Software (basic version available for download).
Caution
• Use cable specified by MAGNAMED. Use SERIAL TO USB converter cable with appropriate
driver for PC.
11 ON / OFF Switch
This key allows turning power on or off the Ventilator Analyzer.
12 DC Power connector
To Next Page
