WAVEFORMS
WF1
WF3
WF1
UPPER
WF2
WF2
LOWER
TP751
TP751
TP302
UPPER
LOWER
TP302
TP301
WF7
AUDIO (L)
1V 0.5ms
WF8
WF9
SPDIF 1V 0.1
µs
Pin 5 of CN1601
Pin 3 of CN1601
Pin 1 of CN1601
AUDIO (R) 1V
0.5ms
V-OUT E-E 0.2V 20
µs
V-OUT 0.5V
50
µs
RF-SW 5V
C-PB
RF-SW 5V 5m
s
0.2V
NOTE:
Input
VCR: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
(WF1~WF3, WF10~WF15)
DVD: POWER ON (STOP) MODE
(WF4~WF6)
CD: 1kHz PLAY
(WF7~WF9)
WF4
WF6
Pin 2 of IC751
WF5
Pin 9 of CN1601
Pin 7 of CN1601
VIDEO-Y 0.2V 20
µ
s
VIDEO-C 0.2V 20
µ
s
VIDEO-CVBS 0.5V 20
µ
s
1-13-1
D7NCFNWF1
