Magnavox SV2000 User Manual

20060927 1-20-1 E8C1TEL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N7DFDKUP
Ref. No. Description Part No.
MCV CBA
Consists of the following:
1VSA15014
MAIN CBA (MCV-A )
DVD OPEN/CLOSE CBA (MCV-C)
SENSOR CBA
----------
----------
1VSA13493
Ref. No. Description Part No.
MAIN CBA (MCV-A )
Consists of the following:
----------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMASSL100
C018 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C020 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C021 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C023 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C030 CERAMIC CAP.(AX) B K 0.068µF/50V CA1J683TU011
C051 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C053 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C301 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C302 CHIP CERAMIC CAP. CH J 390pF/50V CHD1JJBCH391
C303 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
C304 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C305 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C307 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C308 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C309 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C310 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C311 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL1R0
C312 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C313 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL1R0
C314 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C315 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C316 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C317 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C318 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C319 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C320 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C324 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C327 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C328 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C329 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C330 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C331 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C332 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C333 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C336 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C339 CHIP CERAMIC CAP. B K 0.047µF/50V CHD1JKB0B473
C340 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C341 CHIP CERAMIC CAP. B K 0.047µF/50V CHD1JKB0B473
C342 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C343 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C346 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C391 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMASSL101
C392 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C401 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C402 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C403 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C404 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C405 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C406 ELECTROLYTIC CAP. 33µF/6.3V M H7 CE0KMAVSL330
C407 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C408 CHIP CERAMIC CAP. B K 0.012µF/50V CHD1JKB0B123
C409 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C410 CHIP CERAMIC CAP. B K 2700pF/50V CHD1JKB0B272
C411 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C412 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C413 CHIP CERAMIC CAP. B K 6800pF/50V CHD1JKB0B682
C414 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C422 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C423 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C424 CERAMIC CAP. B K 470pF/100V CCD2AKP0B471
C425 FILM CAP.(P) 0.018µF/100V J CA2A183MS029
C430 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJBCH560
C502 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C505 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C507 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C508 CHIP CERAMIC CAP. B K 0.033µF/50V CHD1JKB0B333
C509 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C513 CHIP CERAMIC CAP. CH D 10pF/50V CHD1JDBCH100
C514 CHIP CERAMIC CAP. CH J 22pF/50V CHD1JJBCH220
C515 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJBCH180
C521 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C522 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JKB0B472
C523 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C525 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JKB0B472
C527 CHIP CERAMIC CAP. B K 0.047µF/50V CHD1JKB0B473
C529 CHIP CERAMIC CAP. B K 0.022µF/50V CHD1JKB0B223
C530 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C531 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C532 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C533 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
Ref. No. Description Part No.
