20060927 1-20-2 E8C1TEL
C534 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C535 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C536 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C537 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C540 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C541 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C544 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C560 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C703 ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSL101
C704 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C707 FILM CAP.(P) 0.039µF/50V J CA1J393MS029
C708 ELECTROLYTIC CAP. 0.22µF/50V M CE1JMASDLR22
C709 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C712 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C751 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JKB0B222
C752 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JKB0B222
C760 CHIP CERAMIC CAP. CH J 47pF/50V CHD1JJBCH470
C766 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C772 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C773 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMASSL4R7
C774 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C780 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C781 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C1001# ACROSS THE LINE CAP. 0.068µF/250V CT2E683DC016
C1002 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1003 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C1004 ELECTROLYTIC CAP. 220µF/200V M CA2D221S6008
C1005 CERAMIC CAP. B K 120pF/500V CCD2JKP0B121
C1006# SAFETY CAP. 3300pF/250V CCG2EMA0F332
C1007 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1008 CERAMIC CAP. B K 120pF/500V CCD2JKP0B121
C1013 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C1014 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1015 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C1023 CERAMIC CAP. B K 470pF/500V CCD2JKS0B471
C1029 CERAMIC CAP.(AX) X K 2700pF/16V CCA1CKT0X272
C1030 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1031 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1032 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1033 CERAMIC CAP. YV Z 0.022µF/50V CCD1JZSYV223
C1039 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1040 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1042 ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSL101
C1051 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1070 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C1082 ELECTROLYTIC CAP. 220µF/16V M H7 CE1CMASSL221
C1201 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1202 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1207 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C1208 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C1221 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1222 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1223 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C1224 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C1245 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C1246 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C1247 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1249 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C1351 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C1352 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C1354 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJBCH101
C1355 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
C1359 CHIP CERAMIC CAP. CH D 10pF/50V CHD1JDBCH100
Ref. No. Description Part No.
C1421 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C1422 CHIP CERAMIC CAP. B K 0.1µF/25V CHD1EKB0B104
C1441 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C1442 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1462 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1465 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C1466 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZB0F105
C1482 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1523 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
C1524 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C1531 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JKB0B103
C1532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C2002 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C2012 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZB0F104
DIODES
D013 RECTIFIER DIODE BA158 NDQZ000BA158
D015 SCHOTTKY BARRIER DIODE SB390 NDQZ000SB390
D016 SCHOTTKY BARRIER DIODE SB240-B/P NDQZ000SB240
D019 PCB JUMPER D0.6-P5.0 JW5.0T
D031 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D035 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D040 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D052 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D062 ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3
D063 RECTIFIER DIODE 1N4005 NDQZ001N4005
D080 RECTIFIER DIODE 1N4005 NDQZ001N4005
D082 RECTIFIER DIODE 1N4005 NDQZ001N4005
D504 ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D555 LED MIE-534A2 NPZZM1E534A2
D564 LED(RED) 204HD/E NPQZ00204HDE
D565 LED(RED) 204HD/E NPQZ00204HDE
D566 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D567 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D571 LED(RED) 204HD/E NPQZ00204HDE
D701 ZENER DIODE MTZJT-7733D QDTD00MTZJ33
D777 ZENER DIODE MTZJT-775.6A QDTA0MTZJ5R6
D1001 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1002 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1003 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1004 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1007 PCB JUMPER D0.6-P5.0 JW5.0T
D1008 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1010 RECTIFIER DIODE BA158 NDQZ000BA158
D1011 RECTIFIER DIODE BA158 NDQZ000BA158
D1012 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1018 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1020 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1021 PCB JUMPER D0.6-P5.0 JW5.0T
D1022 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1036 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1037 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1038 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1058 RECTIFIER DIODE 1N4005 NDQZ001N4005
D2001 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D2002 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
ICS
IC301 IC Y/C/A LA71205M-MPB-E QSZBA0RSY037
IC501 IC SYSCON 80PIN QSZAA0RMS048
IC751 IC ANALOG MULTIPLEXER CD4053BNSR NSZBA0TTY093
Ref. No. Description Part No.
