IC1001# PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
IC1002 VOLTAGE REGULATOR PQ1LAX95MSPQ QSZBA0TSH053
IC1004 VOLTAGE REGULATOR PQ1LAX95MSPQ QSZBA0TSH053
IC1201 IC OP AMP KIA4558P/P NSZBA0SJY035
IC1402 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
COILS
L009 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP
LLBD00PKV023
L251 PCB JUMPER D0.6-P5.0 JW5.0T
L303 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L304 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP
LLBD00PKV023
L305 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
L306 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
L400 INDUCTOR 22µH-K-26T LLAXKATTU220
L421 INDUCTOR 47µH-K-5FT LLARKBSTU470
L502 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP
LLBD00PKV023
L503 INDUCTOR 12µH-K-26T LLAXKATTU120
L504 PCB JUMPER D0.6-P5.0 JW5.0T
L701 INDUCTOR 4.7µH-K-5FT LLARKBSTU4R7
L771 PCB JUMPER D0.6-P5.0 JW5.0T
L1001# LINE FILTER 27MH TLF14CB2730R4 LLBG00ZTU034
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1020 RADIAL TYPE CHOKE COIL CW68-470K-
841040NP
LLBD00PKV023
L1350 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1351 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1522 INDUCTOR 47µH-K-5FT LLARKBSTU470
L2001 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
TRANSISTORS
Q031 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q052 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
Q055 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q056 TRANSISTOR KTC3203-Y-AT/P NQSYKTC3203P
Q063 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q064 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q301 TRANSISTOR KTA-1266-GR-AT/P NQS4KTA1266P
Q302 TRANSISTOR KTC3193-Y-AT/P NQSYKTC3193P
Q303 TRANSISTOR KTC3193-Y-AT/P NQSYKTC3193P
Q391 TRANSISTOR KTA-1266-GR-AT/P NQS4KTA1266P
Q421 TRANSISTOR KTA-1266-GR-AT/P NQS4KTA1266P
Q422 TRANSISTOR KTC3203-Y-AT/P NQSYKTC3203P
Q425 RES. BUILT-IN TRANSISTOR KRA103M-AT/P NQSZ0KRA103M
Q426 CHIP TRANSISTOR RN1511(TE85R.F) QQ2Z0RN1511F
Q501 TRANSISTOR KTC3199-BL-AT/P NQS5KTC3199P
Q506 PHOTO TRANSISTOR PT204-6B-12 NPWZT2046B12
Q762 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q763 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q1001# FET 2SK3543(Q) QFWZ2SK3543Q
Q1003 TRANSISTOR 2SC1815-Y(TE2 F T) QQSY2SC1815F
Q1004 TRANSISTOR 2SC2001-T-A-K QQSK2SC2001A
Q1005 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q1006 TRANSISTOR KTA1267-Y-AT/P NQSYKTA1267P
Q1008 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q1011 TRANSISTOR KTC3203-Y-AT/P NQSYKTC3203P
Q1201 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q1202 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q1204 TRANSISTOR KTA-1266-GR-AT/P NQS4KTA1266P
Q1351 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q2002 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Q2003 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
Q2013 TRANSISTOR KTC3199-Y-AT/P NQSYKTC3199P
Ref. No. Description Part No.
RESISTORS
R001# GLASS GLAZE RES. 1/2W J 3.3M Ω RXX2JZLZ0335
R031 CHIP RES. 1/10W J 1k Ω RRXAJB5Z0102
R032 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R034 CHIP RES. 1/10W F 2.2k Ω RRXAFB5H2201
R038 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R039 CHIP RES. 1/10W F 4.7k Ω RRXAFB5H4701
R041 CHIP RES. 1/10W J 18k Ω RRXAJB5Z0183
R042 CHIP RES. 1/10W J 1.8k Ω RRXAJB5Z0182
R056 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R057 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R058 CHIP RES. 1/10W J 180 Ω RRXAJB5Z0181
R063 PCB JUMPER D0.6-P5.0 JW5.0T
R066 CARBON RES. 1/6W J 470 Ω RCX6JATZ0471
R067 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R068 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R069 CHIP RES. 1/10W J 47k Ω RRXAJB5Z0473
R073 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R075 CARBON RES. 1/6W J 4.7k Ω RCX6JATZ0472
R092 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R095 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R301 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R302 CHIP RES. 1/10W J 12k Ω RRXAJB5Z0123
R304 CHIP RES. 1/10W J 1.2k Ω RRXAJB5Z0122
R306 CHIP RES. 1/10W J 3.9M Ω RRXAJB5Z0395
R307 CHIP RES. 1/10W J 100k Ω RRXAJB5Z0104
R308 CHIP RES. 1/10W J 82k Ω RRXAJB5Z0823
R309 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R310 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R311 CHIP RES. 1/10W J 1.8k Ω RRXAJB5Z0182
R312 CHIP RES. 1/10W J 1.8k Ω RRXAJB5Z0182
R313 CHIP RES. 1/10W J 1.8k Ω RRXAJB5Z0182
R314 CHIP RES. 1/10W J 680k Ω RRXAJB5Z0684
R315 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R316 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R317 CHIP RES. 1/10W J 8.2k Ω RRXAJB5Z0822
R318 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R319 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R320 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R321 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R322 CHIP RES. 1/10W J 18k Ω RRXAJB5Z0183
R323 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R324 CHIP RES. 1/10W J 18k Ω RRXAJB5Z0183
R327 CHIP RES. 1/10W F 1.1k Ω RRXAFB5Z1101
R330 CHIP RES. 1/10W J 100k Ω RRXAJB5Z0104
R391 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R392 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R397 CHIP RES. 1/10W J 100 Ω RRXAJB5Z0101
R401 CHIP RES. 1/10W J 27k Ω RRXAJB5Z0273
R402 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R403 CHIP RES. 1/10W J 27k Ω RRXAJB5Z0273
R404 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R405 CHIP RES. 1/10W J 27k Ω RRXAJB5Z0273
R406 CHIP RES. 1/10W J 4.7k Ω RRXAJB5Z0472
R409 CHIP RES. 1/10W J 8.2k Ω RRXAJB5Z0822
R410 CHIP RES. 1/10W J 12k Ω RRXAJB5Z0123
R411 CHIP RES. 1/10W J 330k Ω RRXAJB5Z0334
R412 CHIP RES. 1/10W F 130 Ω RRXAFB5H1300
R413 CHIP RES. 1/10W J 22k Ω RRXAJB5Z0223
R414 CHIP RES. 1/10W J 910 Ω RRXAJB5Z0911
R415 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R416 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
Ref. No. Description Part No.
