1-16-2 E8A61PIN
Notes:
Abbreviation for Active Level:
PWM ----- Pulse Wide Modulation
A/D -------- Analog - Digital Converter
46 OUT
OUTPUT-
SELECT
Output Select H/L
47 IN D-PFG
Drum PG/FG Input
Signal
PULSE
48 IN
POWER-
SAFETY
P-ON Power Supply
Abnormal Detection
Input
L
49 IN C-FG
Capstan Motor
Rotation Detection
Pulse
PULSE
50 - AFG GND -
51 OUT VRO
Servo Standard
Voltage Output
-
52 IN VRI
Servo Standard
Voltage Input
-
53 - AVss AVSS -
54 IN CTLA CTL Amp. AC GND -
55 - AVDD AVDD -
56
IN/
OUT
CTL (+)
Playback/Record
Control Signal (+)
-
57
IN/
OUT
CTL (-)
Playback/Record
Control Signal (-)
-
58 OUT CTL
Amp. Output Control
Signal for Test Point
-
59 - NU Not Used -
60 IN
DVD-POW-
MONITOR
DVD Power Monitor
Signal (P-off = “L”,
P-on = “H”)
H/L
61 - NU Not Used -
62 IN END-S
Tape End Position
Detect Signal
A/D
63 IN AFC
Automatic
Frequency Control
Signal
A/D
64 IN V-ENV
Video Envelope
Comparator Signal
A/D
65 IN PG-DELAY
Video Head
Switching Pulse
Signal Adjusted
Voltage
A/D
66 IN KEY-2
A/D Key Data Signal
2
A/D
67 IN KEY-1
A/D Key Data Signal
1
A/D
68 IN LD-SW
Deck Mode Position
Detector Signal
A/D
69 IN ST-S
Tape Start Position
Detector Signal
A/D
70 OUT VCR-LED-L
VCR Mode LED
Signal Output
L
Pin
No.
IN/
OUT
Signal
Name
Function
Active
Level
71 OUT VCR-LED-L
VCR Mode LED
Signal Output
L
72
OUT DVD-LED-L
DVD Mode LED
Signal Output
L
73 OUT DVD-LED-L
DVD Mode LED
Signal Output
L
74 OUT REC-LED-L
REC Mode LED
Signal Output
L
75
OUT REC-LED-L
REC Mode LED
Signal Output
L
76 OUT
TIMER-
LED-L
TIMER Mode LED
Signal Output
L
77 OUT
TIMER-
LED-L
TIMER Mode LED
Signal Output
L
78 OUT C-ROTA
Color Phase Rotary
Changeover Signal
H/L
79 OUT H-A-SW
Video Head Amp
Switching Pulse
H/L
80 IN H-A-COMP
Head Amp
Comparator Signal
H/L
Pin
No.
IN/
OUT
Signal
Name
Function
Active
Level
