20060927 1-20-5 E8C1TEL
DVD OPEN/CLOSE CBA
SENSOR CBA
R1352 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R1353 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R1354 CHIP RES. 1/10W J 220 Ω RRXAJB5Z0221
R1355 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1395 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1421 CHIP RES.(1608) 1/10W F 75 Ω RRXAFB5H75R0
R1422 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1441 CHIP RES.(1608) 1/10W F 75 Ω RRXAFB5H75R0
R1442 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1443 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1461 CHIP RES.(1608) 1/10W F 75 Ω RRXAFB5H75R0
R1462 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1481 CHIP RES.(1608) 1/10W F 75 Ω RRXAFB5H75R0
R1482 CHIP RES. 1/10W J 75 Ω RRXAJB5Z0750
R1490 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R1521 CHIP RES. 1/10W J 2.2k Ω RRXAJB5Z0222
R2005 CHIP RES. 1/10W J 6.8k Ω RRXAJB5Z0682
R2007 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R2008 CHIP RES. 1/10W J 3k Ω RRXAJB5Z0302
R2009 CHIP RES. 1/10W J 3.3k Ω RRXAJB5Z0332
R2010 CHIP RES. 1/10W J 5.6k Ω RRXAJB5Z0562
R2011 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R2012 CHIP RES. 1/10W J 33k Ω RRXAJB5Z0333
R2013 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
R2028 CHIP RES. 1/10W J 10k Ω RRXAJB5Z0103
R2031 CHIP RES. 1/10W J 22k Ω RRXAJB5Z0223
R2051 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R2052 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R2053 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R2054 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
SWITCHES
SW501 TACT SWITCH KSM0614B SST0101HH013
SW502 TACT SWITCH KSM0614B SST0101HH013
SW505 TACT SWITCH KSM0614B SST0101HH013
SW508 TACT SWITCH KSM0614B SST0101HH013
SW509 TACT SWITCH KSM0614B SST0101HH013
SW511 LEAF SWITCH MXS01830MVP0 SSC0101MCE03
SW512 ROTARY MODE SWITCH SSS-53MD SSR0106KB003
SW513 TACT SWITCH KSM0614B SST0101HH013
SW514 TACT SWITCH KSM0614B SST0101HH013
SW515 TACT SWITCH KSM0614B SST0101HH013
SW516 TACT SWITCH KSM0614B SST0101HH013
SW2002 TACT SWITCH KSM0614B SST0101HH013
SW2003 TACT SWITCH KSM0614B SST0101HH013
SW2005 TACT SWITCH KSM0614B SST0101HH013
SW2006 TACT SWITCH KSM0614B SST0101HH013
MISCELLANEOUS
2B11 HEAD SHIELD H9600UD 0VM306770
2B15 BUSH LED(F) H3700UD 0VM409508
2L062 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L082 SCREW S-TIGHT M3*5 BIND+ 3*5 BIND+ GBHS3050
A4 JACK BOARD(TUNER) H9600UD 0VM306675
A5 JACK BOARD(RCA) H9610UD 0VM306766
AC1001# AC CORD W/O A GND WIRE UL/CSA 1770
BLACK
WAC0172LTE17
F1001# FUSE TIME RAG SIC 1A 250V UC PSE PEG20C0W3002
FH1001 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH1002 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JC23 CHIP RES.(1608) 1/10W 0 Ω RRXAZB5Z0000
JK751 RCA JACK MSP-283V-B-324NILF01 JXRL040LY141
JK752 RCA JACK MSP-282V-14 NI FE LF JXRL030LY137
JK753 RCA JACK MSP-281V42-B(B110) JXRL010LY142
JK755 RCA JACK MSP-281V40-B(B110) JXRL010LY138
Ref. No. Description Part No.
JK756 RCA JACK 2P MSP-282V-12 NILF(B11 JXRL020LY121
JK1202 RCA JACK MSP-281V41-B(B110) JXRL010LY140
JK1401 S TYPE JACK MDC-050V-2.4 LF(B110 JXEL040LY003
JK1403 RCA JACK MSP-283V-B-752 NI LF JXRL040LY122
RM2001 REMOTE RECEIVER PIC-37042LU USESJRSKK033
T001# SWITCHING TRANSFOMER BCK-28-0550 LTT00CPXB017
TP301 PCB JUMPER D0.6-P16.5 JW16.5T
TP302 PCB JUMPER D0.6-P16.0 JW16.0T
TP506 PCB JUMPER D0.6-P8.0 JW8.0T
TP507 PCB JUMPER D0.6-P7.0 JW7.0T
TP513 PCB JUMPER D0.6-P7.5 JW7.5T
TP751 PCB JUMPER D0.6-P23.5 JW23.5T
TP753 PCB JUMPER D0.6-P25.5 JW25.5T
TP754 PCB JUMPER D0.6-P22.5 JW22.5T
TU701 TUNER UNIT VH025AFE UTUNNTUSP026
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
W002 WIRE ASSEMBLY FFC 21P 21 240 WHITE WX1E8C00-002
W006 WIRE ASSEMBLY FFC 13 192 WHITE WX1E8A00-005
X301 XTAL 3.579545MHz(20PPM) FXC355LLN004
X502 XTAL DT38 32.768kHz FX0323LDS001
Ref. No. Description Part No.
DVD OPEN/CLOSE CBA (MCV-C)
Consists of the following:
----------
SWITCH
SW2001 TACT SWITCH KSM0614B SST0101HH013
MISCELLANEOUS
W011 WIRE ASSEMBLY 02 130 GRAY WX1E8A00-001
Ref. No. Description Part No.
SENSOR CBA
Consists of the following:
1VSA13493
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 NPWZT2046B12
Q504 PHOTO TRANSISTOR PT204-6B-12 NPWZT2046B12
Ref. No. Description Part No.
To Next Page
