QUANTITY PART # DESCRIPTION
1 30-E Valve Pushrod Set
1 30-H Valve Set
1 30-K Rocker Arm Set
1 30-L Rocker Arm Cover with Screws
1 30-M Cam Gear Cover with Screws
1 30-N Cylinder Head with Complete Valve Set
1 52-B Carburetor Rotor Bolt Set
1 12114 Fuel Nipple - No Gasket
4 12126 Backplate Bolt Set
2 12518 Intake Pipe Screws
1 12811 Throttle Arm Lock Nut
1 12812 Throttle Arm
1 12814 Throttle Barrel Spring
1 12819 Fuel Nipple
1 12845 Needle Valve O-Ring
1 12833 Needle Valve Detent Spring
1 28110 Rear Bearing
1 30101 Crankcase
1 30102 Backplate
1 30108 Fixed Length Bushing
1 30109 Front Bearing
1 30210 Crankshaft
1 30111 Backplate Gasket
2 30112 Cylinder Head Gasket Set
1 30113 Carburetor Hold Down Bolt
1 30204 Connecting Rod
1 30213 Wrist Pin Assembly
1 30219 Drive Washer
1 30228 Prop Nut and Washer Set
1 30231 Piston
1 30232 Cylinder Sleeve
1 30236 Piston Ring
1 30601 Muffler Assembly with Exhaust Pipe
2 30709 Cam Gear Bearing Set
1 30714 Cam Gear
1 30732 Cam Gear Cover Gasket
1 30801 Carburetor Assembly - Complete
1 30813 Throttle Barrel
1 30844 Idle Mixture Screw
1 30863 Carburetor Body with Spray Bar
1 52831 Intake Pipe Gasket
1 52860 Needle Valve Set - Complete
1 52861 Needle Valve with O-Ring
4 80122 Head Bolt Set
To order replacement parts, visit your nearest
Magnum Engines dealer or call the Magnum
Engines Service Center direct at 1-714-963-0329.
Parts are listed here in numerical order.
PARTS LIST
