A-19
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Anti Freeze
Frozen water can damage the cylinders and radiator.
It is necessary, if ambient temperature falls below 0
0
C
(32
0
F) to remove cooling water after operating or to
add anti freeze to it.
Refer to SAE J1034 and SAE J814C for the procedure
of mixing water and antifreeze.
NOTE :
• When the cooling water level drops add only clear
water. In case of leakage, add anti freeze and
water is the specified mixing ratio.
• Anti freeze absorbs moisture keep unsealed
anti freeze in the lightly sealed container.
• Do not use radiator clearing solution when anti
freeze has been added to the cooling water.
(Anti freeze contains an anti corrosive agent,
which will react with radiator cleaning agent
forming sludge which will affect the engine parts)
Vol % Freezing Point Boiling Point
Anti Freeze
0
C
0
F
0
C
0
F
40 – 24 – 12 106 222
50 – 37 – 35 108 226
