Mahindra 35 Series User Manual

B-4
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Front Axle & Engine
4. Disconnect the gas spring from hood and then
remove hood from hinge assembly.
5. Remove side panels from locating points.
6. Disconnect horn.
7. Loosen the Air cleaner inlet hose, connections
from the intake manifold and air cleaner.
8. Remove air cleaner by removing it from
bracketaries.
9. Remove the radiator inlet and outlet hoses.

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
