B-11
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Transmission & Rear Axle Assembly
13. Remove the fuel tank from mounting brackets.
14. Disconnect wiring harness of fuel level sensing
float.
15. Disconnect the pipe from suction manifold to
hydraulic filter, Filter to oil pump & plug the pipes.
16. Dismantle the oil filter.
17. Disconnect the brake linkages at brake actuating
lever.
18. Remove the seat from mounting channels with
LH & RH mounting channels.
