I-34
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Hydraulics
17. REMOVE, INSPECT AND INSTALL TOP LINK
BRACKET ASSEMBLY
separate it.
Replace as necessary
with spring and cover assembly, loosen two
screws (E) and one set screw (F).
out top link bracket.
1. Loosen screw (A) of tie rod (B).
2. Remove nut (C) of top link bracket (D) to
3. Check top link bracket for any wear or damage.
4. To remove top link bracket assembly completely
5. Remove lock roll pin (G) of pin (H) , to take
