Mahindra 4035 Service Manual

B-5
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Front Axle & Engine
10. Remove the radiator mounting bolts and remove
the radiator.
11. Remove the front bottom grill and bonnet locking
bracket.
12. Disconnect the LH / RH hoses to the power
steering cylinder and plug the hoses to prevent
oil spillage.
13. Remove the propeller shaft guards.
14. Remove the propeller shaft bearing from support
bracket.

Mahindra 4035 Specifications

General

Engine Power	35 HP
Engine Type	Diesel
Transmission	8 Forward + 2 Reverse
Hydraulic System	Open center
PTO Power	30 HP
Drive Type	4WD
No. of Cylinders	3
Steering	Power Steering
Wheelbase	73.2 inches
Ground Clearance	13.4 inches
Fuel Capacity	45 liters
Displacement	2.5 liters
Brakes	Oil Immersed
Fuel Tank Capacity	45 liters
