Mahindra 5035 Service Manual

E-5
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Transmission
1. SPECIFICATION
Details
Backlash
Minimum Maximum
Shuttle Gears
Forward 0.006” 0.012”
Reverse 0.006” 0.012”
Speed Gears
1
st
Pair 0.007” 0.012”
2
nd
Pair 0.007” 0.012”
3
rd
Pair 0.007” 0.012”
4
th
Pair 0.007” 0.012”
Range Gears
Low 0.007” 0.012”
Medium 0.007” 0.012”
High 0.007” 0.012”
Bull Gear & Pinion 0.005” 0.010”
2. FLOATS
Sr. Location Float (in Inch) Assembly Method
No.
Minimum Maximum
1. Between gear reverse driving 0.004” 0.008” Graded Spacer
shuttle option & spacer.
2. Between speed top-shaft rear bearing 0.004” 0.008” Graded Bush
& speed bearing front 1st Gear
3. Between speed countershaft rear 0.004” 0.008” Graded Shim
bearing & circlip
4. Between 4WD Idler Gear & the washer 0.011” 0.016” Graded Washer
Front
35 SERIES - TRANSMISSION

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
