Mahindra 5035 Service Manual

E-53
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Rear PTO Cover
Removal of Rear PTO Cover
Assembling Rear PTO Cover
c. Now take out rear PTO cover from locating pins
by slight tapping.
2. ASSEMBLY
a. Put two stud locator in Transmission-case.
b. Locate PTO cover assembly in stud locator. Slowly
push the assembly and precaution to be taken
for wet clutch assembly matches with the hub
properly to avoid damage of liners.
c. After assembly, check smooth rotation of wet
clutch.
d. Then clamp the mounting bolts to the specified
torque values.
A. REAR PTO COVER
1. DISMANTLING
a. Loosen bolt (A) of rear PTO cover (B).
b. Loosen bolt (C) of plate retainer (D).
NOTE: Hydraulic Housing on top of transmission case
to be removed for dismantling of Rear PTO
Cover.

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
