Mahindra 5035 Service Manual

B-3
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Front Axle & Engine
SPLITTING BETWEEN THE FRONT AXLE AND ENGINE
1. Using the special tool - Rail & Trolley Jack - support
the Engine assembly. Apply Tractor parking brakes
and place wedges to hold the rear wheels. Drain
the water from the Radiator, from two places :
a. Engine Block side drain plug.
b. Radiator bottom tank drain plug.
2. Open the hood.
Negative
(–)
Positive
(+)
3. First remove the battery cable from its negative
terminal & then remove battery cable from
positive terminal. Remove the battery.
NOTE : Always disconnect the negative terminal first.

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
