► TRACTOR CONTROLS
► SPEED CONTROL PEDAL
The Speed Control Pedal is located in the RHS of the Operator floor.
Depress the forward speed control pedal to move forward.
Depress the reverse speed control pedal to move backward.
The speed control pedal will return to neutral position
and the tractor will stop when the speed control pedal is released.
► THROTTLE LEVER (HAND THROTTLE)
The hand operated throttle lever is located on the RHS
of the dash cover.
To increase the engine speed, pull the lever downward.
To decrease the engine speed, push the lever upward.
The Lever can be left in any position between idle and maximum
as required.
33
Steering Wheel
Brake Pedal
4WD Shift Lever
Rear/Mid PTO Lever
Sub Gear Lever
Forward/Reverse
Speed Control pedal
Position Lever
Throttle Lever
To Next Page
