99
SKID STEER TOOL CARRIER ATTACHMENT
Reference Description Part No. Qty.
0..............................Skid Steer Tool Carrier Attachment (complete)........................1304-3164................................1
1..............................Skid Steer Tool Carrier Frame..................................................1304-3165 ................................1
2..............................Handle, LH ...............................................................................1304-3060................................1
3..............................Handle, RH...............................................................................1304-3061 ................................1
4..............................Hex Head Cap Screw 5/16"-18NC x 5-1/2" .............................0545-2044 ................................2
5..............................Flat Washer 5/16".....................................................................0540-2001 ................................2
6..............................Hex Lock Nut – Nylock 5/16"-18NC.........................................0555-2133................................2
7..............................Compression Spring.................................................................0565-2003................................2
8..............................Pivot Pin...................................................................................1304-3067 ................................2
9..............................Pivot Pin...................................................................................1304-3041 ................................2
10............................Hex Lock Nut – Dimpled 1/2"-13NC ........................................0555-2136................................4
11 ............................Stop Assembly..........................................................................1304-3045 ................................2
12............................Compression Spring.................................................................0565-2004 ................................2
13............................Rod Assembly ..........................................................................1304-3068 ................................2
14............................Locking Pin...............................................................................1304-3066 ................................2
15............................Socket Head Shoulder Bolt 3/8" ..............................................0546-1102 ................................2
16............................Roll Pin 5/16" x 1-3/4" ..............................................................0561-3277 ................................2
17............................Pivot Assembly.........................................................................1304-3070 ................................2
18............................Decal Warning..........................................................................0595-3051 ................................1
19............................Grease Zerk ¼”-28...................................................................0530-1038................................4
20............................Decal Important, LH .................................................................0595-3144................................1
21............................Decal Important, RH.................................................................0595-3145 ................................1
22............................Pivot Pin 4.11”..........................................................................0551-3073 ................................4
23............................Carriage Bolt 3/8”-16 x 1.25”....................................................0546-1137 ................................4
24............................Hardened Flatwasher 3/8” .......................................................0540-2021 ................................4
25............................Stover Hex Locknut 3/8”-16 .....................................................0546-1119.................................4
35 Series 4WD, Model - 3535 & 4035 Loader June’08
