21. PARTS MANUAL
Illustrations
All parts are illustrated in "exploded views" which show the individual parts in their normal relationship to each
other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Reference
Number" column and are followed by the quantity required and description.
Directional Reference
Right hand (RH) and left hand (LH) sides are determined by standing at the rear of the unit and facing in the
direction of forward travel.
Parts Order
Orders must give the complete description, correct part number, the total amount required, the product model, all
the necessary serial numbers, the method of shipment and the shipping address.
35 Series 4WD, Model - 3535 & 4035 Loader June’08
