33
3.4.17. Install toolbox to right hand centerbracket using
hex head cap screw 5/8”-12 x 2.5” and stover hex
locknut 5/8”-12 as shown.
Toolbox
Hex Head Cap Screw 5/8”-12 x 2.5”, Stover Hex
Locknut 5/8”-12, 2 places
3.4.18. Install step removed in step 3.2.3 on right hand
rear rail using original step hardware as shown.
Right hand Rear Rail
Right Hand Step
Install using original hardware
35 Series 4WD, Model - 3535 & 4035 Loader June’08
