48
7.1.4. Remove handle pins from bearing boxes.
Bearing box
Handle pin
7.1.5. Remove parking stand from storage position in
the boom cross tube. Return hairpin cotter to storage
position.
Hairpin cotter
in storage position
Parking stand
in storage position
35 Series 4WD, Model - 3535 & 4035 Loader June’08
