89
MOUNTING BRACKETS AND HARDWARE
Reference Description Part No. Qty.
1..............................Center Bracket LH....................................................................1245-3516................................1
2..............................Center Bracket RH...................................................................1245-3517 ................................1
3..............................Rear Rail LH.............................................................................1207-3110 ................................1
4..............................Rear Rail RH............................................................................1207-3111.................................1
5..............................Cross Member..........................................................................1209-3066 ................................1
6..............................Spacer Assembly LH................................................................1245-3602 ................................1
7..............................Spacer Assembly RH ...............................................................1245-3603................................1
8..............................Hex Head Cap Screw ¾”-10 x 2.0” Grade 8............................0548-2230 ................................4
9..............................Hex Head Cap Screw ¾”-10 x 1.75” Grade 8..........................0548-2229................................8
10............................Disc-Lock Washer ¾”...............................................................0540-2017..............................16
11 ............................Stover Hex Locknut ¾”-10 .......................................................0546-1130 ................................4
12............................Hex Head Cap Screw 14-1.50 x 65mm Grade 10.9................0569-2401................................8
13............................Hex Head Cap Screw 14-2.0 x 35mm Grade 10.9..................0569-2147................................4
14............................Disc-Lock Washer 9/16”...........................................................0540-2009 ..............................24
15............................Hex Head Cap Screw 5/8”-12 x 2.0" Grade 8..........................0548-2166 ..............................18
16............................Disc-Lock Washer 5/8”.............................................................0540-2020 ..............................16
17............................Hardened Flatwasher 5/8” .......................................................0540-2004 ..............................18
18............................Stover Hex Locknut 5/8”-12 .....................................................0546-1134 ..............................10
19............................Hex Head Cap Screw ½”-13 x 2.0” Grade 5............................0545-2108................................6
20............................Stover Hex Locknut ½”-13 .......................................................0546-1122 ................................6
35 Series 4WD, Model - 3535 & 4035 Loader June’08
