Mahindra ML 120 3535 - Hydraulic Valve and Hardware

91
HYDRAULIC CYLINDERS AND HOSES
Reference Description Part No. Qty.
1..............................Cylinder, Tilt..............................................................................3150-2106 ................................2
2..............................Cylinder, Lift .............................................................................3160-2076................................2
3..............................Hose Cover ..............................................................................1212-2020 ................................1
4..............................Top Hose Cover .......................................................................1212-2019 ................................1
5..............................Side Hose Cover......................................................................1212-2021 ................................1
6..............................Sponge Rubber 3"....................................................................0554-2010 ................................6
7..............................Hydraulic Hose Assembly 3/8” x 54" LHLCBE.........................0582-2508848054....................1
8..............................Hydraulic Hose Assembly 3/8” x 75" LHLCRE.........................0582-2508848075....................1
9..............................Hydraulic Hose Assembly 3/8” x 44" LHTCBE.........................0582-2508848044....................1
10............................Hydraulic Hose Assembly 3/8” x 46" LHTCRE ........................0582-2508848046 ....................1
11 ............................Hydraulic Hose Assembly 3/8” x 25" RHLCBE ........................0582-2508848025....................1
12............................Hydraulic Hose Assembly 3/8” x 45" RHLCRE........................0582-2508848045....................1
13............................Hydraulic Hose Assembly 3/8” x 17" RHTCBE........................0582-2508848017....................1
14............................Hydraulic Hose Assembly 3/8” x 22" RHTCRE........................0582-2508848022 ....................1
15............................Hydraulic Hose Assembly 3/8” x 103" Tee to Quick Couplers .0582-2106888103 ....................4
16............................Fitting Tee.................................................................................0586-4828-828.........................4
17............................Flatwasher 5/16" ......................................................................0543-2006 ................................5
18............................Stover Hex Nut 5/16"-18NC .....................................................0546-1121 ................................5
19............................Hydraulic Adapter.....................................................................0586-3108-408.........................2
20............................Hose Sock – 2.6” I.D. x 48”......................................................0554-2030 ................................1
21............................Tie Strap Blue .14" x 5.5" .........................................................0554-2001................................2
................................Tie Strap Red .14" x 5.5"..........................................................0554-2002 ................................2
................................Tie Strap Yellow .14" x 5.5" ......................................................0554-2003 ................................2
................................Tie Strap Green .14" x 5.5" ......................................................0554-2004 ................................2
22............................Tie Strap Black 5/16" x 14".......................................................0554-1013 ................................4
23............................Male Quick Coupler..................................................................0580-6202 ................................4
NOTE: See cylinder drawing for grease zerk information.
35 Series 4WD, Model - 3535 & 4035 Loader June’08
