DESCRIPTION LOCATION IC No PINS M/F CONNECTOR VIEW
INTER-CONNECTORS (IC) - LOCATIONS/PINS/VIEWS
IP to ENGINE ROOM
A-PILLAR RIGHT
30
6M
CLOCK SPRING to
STEERING
SWITCHES
Steering wheel
31
8F
FUEL PUMP to
ENGINE
Engine
32
2M
IP TO FLOOR
A-PILLAR RIGHT
33
1F
ABS to ENGINE
WHEEL HOUSE
PANEL -RIGHT
34
1M
ABS to REAR
SENSOR PIGTAIL
Near to FUEL TANK
35
2M
IP to CLUSTER
INSTRUMENT
CLUSTER
36
2M
TRANSMISSION to
CAHSIS
CHASIS CROSS
MEMBER
37
14 F
TRANSMISSION to
CHASIS
CHASIS CROSS
MEMBER
38
16 F
TRANSMISSION to
FLOOR
UNDER CENTRE
CONSOLE
39
20 M
FLOOR to IP
A-PILLAR RIGHT
40
22 M
FLOOR to IP
A-PILLAR RIGHT
41
20 M
M - MALE CONNECTOR WITH PINS
F - FEMALE CONNECTOR
MAN-00039
Rev1/Sep2008 9
