3 VEHICLE OVERVIEW
3.1 Front Overview
U52C01
A B C D E
JK G FHI
A Canopy
B Outside Rear View Mirror
C Windshield
D Windshield Wiper
E Hood lock
F Head lamp
G Front Tow Hook
H Front Parking Lamp
I Front Right Turn Signal Lamp
J Side Repeater Lamp
K Side Footstep
3.2 Side Overview
U52C02
BA
CDFH G E
A Spare Wheel
B Canopy Flap
C Fuel Filler Lid
D Reversing Lamp
E Rear Stop/Brake Lamp
F Rear Right Turn Signal Lamp
