Mahindra THAR CRDe 2015 - Fuses and Relays

© Copyright Mahindra & Mahindra Ltd. 042015
2-3
2.3 Fuses and Relays
Types of Fuses
• Blade Fuse
• Mini Fuse
• Slow blow Maxi fuse
3
0
A
1
0
1
0
BLADE FUSE MINI FUSE SLOW BLOW
MAXI FUSE
Switch OFF the ignition and all electrical equipment before touching or
attempting change a fuse. Use a fuse puller to remove a fuse. Fit replacement
fuse with the same rating as the one you have removed. Do not modify the
electrical system of your vehicle, contact Mahindra authorized dealer if
required.
Blown fuse can be identified by a break in the filament.
2.3.1 Cabin Compartment Fuse Box (IP W/H)
Cabin Compartment Fuse Box (IP W/H) is located below the instrument panel on
the driver side.
U52B04
4
0
1
5
3
0
1
0
5
5
1
0
1
0
1
5
1
5
1
5
1
5
1
0
1
0
1
0
1
0
1
0
1
0
2
0
U52B15
15A
H/ L
LOW
AUDIO
ACC
TURN/
REV.
WIPER
WASHER
N/ A
HEATER
FOG
LAMP
CLUSTER
ECU
K28
IMMO
IGN
10A10A10A15A10A10A20A5A
15A
H/ L
HIGH
PARK
LAMP
HORN/
HAZARD
ROOF/
ENGINE
LAMP
AC
COMP
N/ A
IMMOB/
DIAG
AUDIO
BATT
BLOWER
FAN
HAZARD
CTRL
10A15A10A10A5A10A30A15A
FUSE
PULLER
COND.
FAN
40A
GENERAL
