7-4
© Copyright Mahindra & Mahindra Ltd.042015
Head lamp Flash
Pull the lighting control stalk (from the head lamp low beam position) towards the
steering wheel to instantaneously flash the head lamp high beam.
7.4.6 Head Lamp Leveling System
When the vehicle is either fully or partially loaded, it may have an upward inclination
disturbing the head lamp aiming. A correct head lamp setting provides good visibility
to the driver with minimum inconvenience to other road users.
To properly aim the head lamp beam, use the head lamp leveling switch. This switch
is located on the right side of the steering column shroud in the instrument panel.
This switch has five positions marked as 0, 1, 2, 3, 4.
Switch Position
Vehicle Loading Condition
0
Driver only
0 Driver + Co-driver
1
All Seated (Driver + 5)
3
All Seated (Driver + 5) + Boot Loaded
2
Driver + Boot Load as specified in GVW
4
Dummy
The head lamp leveling should be done when the head lamp low beam is ON.
FEATURES AND CONTROL
