7-5
Head lamp Flash
Pull the lighting control stalk (from the head lamp low beam
position) towards the steering wheel to instantaneously flash the
head lamp high beam.
7.4.6 Head Lamp Leveling System
When the vehicle is either fully or partially loaded, it may have an
upward inclination disturbing the head lamp aiming. A correct head
lamp setting provides good visibility to the driver with minimum
inconvenience to other road users.
To properly aim the head lamp beam, use the head lamp leveling
switch. This switch is located on the right side of the steering
column shroud in the instrument panel. This switch has five
positions marked as 0, 1, 2, 3, 4.
Switch
Position
Vehicle Loading Condition
0
Driver only
0 Driver + Co-driver
1
All Seated (Driver + 5)
3
All Seated (Driver + 5) + Boot Loaded
2
Driver + Boot Load as specified in GVW
4
Dummy
The head lamp leveling should be done when the head lamp low
beam is ON.
FEATURES AND CONTROL
