© Copyright Mahindra and Mahindra Ltd. 062016
12-5
3.
Lift the hood and support it by the stay rod
• Do not open the hood immediately after a drive; the engine
compartment will be very hot
• Always double check to be sure that the hood is firmly
latched before driving away. If it is not latched properly, the
hood could open while the vehicle is being driven, causing a
total loss of visibility, resulting in an accident
• Do not move the vehicle with the hood in the raised position,
as vision is obstructed
Follow the below steps to close the hood;
1. Pull the hood down to a few inches above its fully closed
position
2. Now, release the hood and allow it to fall by its own weight.
The secondary latch is engaged now.
3. Firmly press the hood down with both your hands to engage
the primary latch.
4. Pull the hood lock lever slightly up and hook it onto the hood
on either sides
MAINTENANCE
