B. Service Parts
Beginning Manufacturing Date: April 2016
Ending Manufacturing Date: Active
1
2
3
4
5
6
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Assembly
LOGSMDVI30 Y
1
Log 1
SRV2219-701
2
Log 2
SRV2219-704
3
Log 3
SRV2219-703
4
Log 4
SRV2219-702
5
Log 5
SRV2219-705
6 Log 6 SRV2219-706
7 Termination Plate Assembly 2206-013
Flex Pipe Handle 438-351
Gasket 2206-178
8
Grate Assembly
2206-016
9 Burner Assembly 2206-008 Y
10 Base Pan 2206-127
11
Valve Assembly
Refer to valve page
12
Glass Door Assembly
GLA-2206 Y
13
Control Panel
2205-129
14
Blower Assembly
GFK210MAJ
15
Wire Assembly
2206-068 Y
16
Cord Assembly
2201-017 Y
Fuse Wire Assembly
Qty 2 req 2206-085 Y
Additional service part numbers appear on following page.
7/18
Log Set Assembly
MDVI30IN, MDVI30IL
Ruby 30” Gas Insert - DV
7
8
9
10
11
12
13
14
15
16
Service Parts
To Next Page
