Major tech MT550 - Page 6

6
DC Voltage
Range Resolution Accuracy Input Overload
Impedance Protection
1000V 1V
±(0.8%+3)
10MΩ 1000Vrms
AC Voltage (40Hz~400Hz)
Range Resolution Accuracy Input Overload
Impedance Protection
750V 1V ±(1.2%+10) 10MΩ 750Vrms
Meg OHMS
Range Resolution Accuracy Terminal Voltage
200MΩ/250V 0.1MΩ 250V +10%~-0%
±(3%+5)
200MΩ/500V 0.1MΩ 500V +10%~-0%
0~1000MΩ/1000V
1000~2000MΩ 1MΩ
±(5%+5)
1000V +10%~-0%
/1000V
Range Test Current Short Circuit Current
200MΩ/250V 250KΩ(load)
200MΩ/500V 500KΩ(load)
0~1000MΩ 1mA ≤1mA
/1000V
1000~2000MΩ 1MΩ
/1000V
