Makeblock mDrawBot Kit - Page 14

mEggBot
Motor A
Motor B
Egg
(2)
1
Screw M4×8(8)
(2)
2
(1)
(1)
Screw M3×8(4)
3
Screw M4×16(2)
Nut M4(2)
1
2
5
(1)
Screw M4×22(2)
Nut M4(4)
(2)
6
Nut M4(2)
Flange Bearing
4×8×3
Plastic Gasket
4×8×1
7
(1)
4
(1)
Screw M3×5(1)
1.5mm
mScara mSpider mEggbot mCar mScara mSpider mEggbot mCar
24 25
(5~8) mm
Structure Diagram
Note: Make sure to assemble the robot in strict accordance with the requirements
from P5 - P7, otherwise it may result in inaccuracy or poor performance.
