Makeblock Orion & Battery Holder
Headless Set Screw M3×5
Wrench
Nut M4
Hex Allen Key 1.5mm
Screw M3×8
Screw M4
Tools
Pen Lift Mechanism
Assembled Diagram
Rubber Bank
Pen
9g Servo Motor
Servo Motor Bracket
Pen Holder and V
Clamp(together)
Square Nut M4
1
Pen Holder(1)
Plastic Hinge(1)
Hinge Gasket(1)
Screw M4×16(2)
Nut M4(2)
O
X
2
(1)
(1)
Nut M4(2)
Screw M4×8(2)
15°~45°
※Before tightening the two screws, make sure the Pen Holder
can be easily lifted up for 15°~45°.
3
Nut M4(1)
Screw M4×22(1)
98
Note: Make sure to assemble the robot in strict accordance with the requirements
from P5 - P7, otherwise it may result in inaccuracy or poor performance.
Screw M4×16
Makeblock Orion
Plastic Ring
4×7×3mm
Base Bracket
Nut M4
Plastic Rivet R4060
Battery Holder
Base Bracket
Batteries
Screw M4×8
Screw M4×8
Nylon Stud M4×30
To Next Page
