Makeblock mDrawBot Kit - Screw M3×8; Screw M4; Nut M4

15
Screw M4×16(2)
(1)
16
(1)
Screw M3×5(1)
1.5mm
(1)
1
2
17
O
X
18
Screw M3×8(4)
To avoid over-tension,do not tighten
the screw.
Timmy Pulley 18T
21
(2)
O
X
22
(1)
Screw M3×5(1)
1.5mm
1
2
Shaft Collar 4mm
19
(1)
Nut M4(1)
20
Screw M4×16(4)
(1)
(1)
Nut M4(4)
(1)
(2)
15
14
mScara mSpider mEggbot mCar
10
mScara mSpider mEggbot mCar
※Use one hand to press the Shaft Collar
downward to minimize the gap between
the parts, meanwhile use the other hand
to tighten the M3x5 screw.
