Makita BO3710 Technical Information

P 5/ 7
Repair
[3] DISASSEMBLY/ASSEMBLY
[3]-3. Field
ASSEMBLING
Fig. 11
1) Facing the red lead wire side to Front grip side, assemble Field as illustrated in Fig. 13.
2) As for the further step, take the reverse step of Disassembly.
Red Lead wire
Front grip
Front grip side

Makita BO3710 Specifications

General

Power	- W
Uncertainty K	1.5 m/s²
Maximum paper size	93 x 228 mm
Vibration emission	3.5 m/s²
Dust container type	Dust bag
Type of sander	Orbital sander
Dust extraction port	Yes
Sound pressure level	72 dB
Sound level uncertainty	3 dB
Idle oscillation rate (max)	11000 OPM
Power source	AC
AC input voltage	110-240 V

Weight and Dimensions

Weight	1500 g
Sanding plate size (WxD)	92 x 185 mm
