Makita DF331D Repair Manual

October 2015
3. CIRCUIT DIAGRAM
Color index of lead wires' sheath
Black
Red
Blue
White
Yellow
Figure 22
16AWG
16AWG
Line filter
B
φ
10-20mm
(if used)
DC Motor
Red mark
Resistor
B- B+
M2
M1
Terminal
Line filter
A
φ
10-11mm
(if used)
T terminal
24
AWG, UL1685
AWG
16
AWG
22
16AWG
Straight receptacles
W
ith lock
(#
187, t=0.8)
LED
circuit
Flag receptacle
s
w/o lock
(#
187, t=0.5)
Flag receptacle
W
ith lock
(#
250, t=0.8)
Flag receptacle
W
ith lock
(#
187, t=0.8)
＋
－
AWG: American wire gauge
16 / 18

Makita DF331D Specifications

General

Voltage	10.8V
Battery Type	Li-ion
Max Torque	30 Nm
Chuck Capacity	0.8 - 10 mm
Max. in steel	10 mm
Max. in wood	21 mm
Max Torque S/H	14 / 30 Nm
Length	189 mm
Weight	1.1 kg
Type	Drill Driver
Net weight	1.1 kg
