Makita DF331D Repair Manual

October 2015
ABOUT THIS MANUAL
The number in the parenthesis () is the item number on the exploded diagram (Figure 1, Figure 2, Figure 3).
2. REPAIR
Repair the machine in accordance with “Instruction manual” or “Safety instructions”.
2.1. NECESSARY REPAIRING TOOLS
Code No. Description Use for
1R003 Retaining ring pliers ST-2N removing Ring spring 10
1R212-A Tip for retaining ring pliers use with 1R003 in order to remove/ assemble Ring spring 10
1R212-B Plate set (with screws)
1R231 1/4 " H ex. shank bit for M8 disassembling Drill chuck (10)
1R359 Chuck removing tool disassembling Drill chuck (10)
If it is impossible to remove as per the illustration in 3-2-1, refer
to Repair Tool List.
- Hex wrench 8 disassembling Drill chuck (10)
- Bit adapter disassembling Drill chuck (10)
7 / 18

Makita DF331D Specifications

General

Voltage	10.8V
Battery Type	Li-ion
Max Torque	30 Nm
Chuck Capacity	0.8 - 10 mm
Max. in steel	10 mm
Max. in wood	21 mm
Max Torque S/H	14 / 30 Nm
Length	189 mm
Weight	1.1 kg
Type	Drill Driver
Net weight	1.1 kg
