Makita DLM432PT2 User Manual

3
1
2
Fig.33
1
2
3
Fig.34
1
2
3
4
Fig.35
6

Makita DLM432PT2 Specifications

General

Type	Push lawn mower
Motor type	Brushless
Cutting width	430 mm
Product color	Green
Cutting system	Rotary blades
Housing material	Acrylonitrile Butadiene Styrene (ABS), Polypropylene (PP)
Number of blades	2
Number of wheels	4 wheel(s)
Rotational speed	3600 RPM
Maximum lawn area	575 m²
Mulching function	-
Maximum cutting height	75 mm
Minimum cutting height	20 mm
Grass collecting volume	50 L
Number of height positions	13
Cutting clearance adjustment	Yes
Cutting clearance adjustment type	Stepped
Power source	Battery
Battery voltage	18 V

Weight and Dimensions

Depth	1490 mm
Width	460 mm
Height	1045 mm
Weight	16800 g
