Makita DSS501 User Manual

6
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heaviest
combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
• Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.
WARNING:
• Only use the battery cartridges and chargers listed above. Use of any other battery cartridges and chargers may
cause injury and/or fire.
Intended use
ENE028-1
The tool is intended for performing lengthways and
crossways straight cuts and mitre cuts with angles in
wood while in firm contact with the workpiece.
General power tool safety
warnings
GEA010-2
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
Save all warnings and
instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
CORDLESS CIRCULAR SAW
SAFETY WARNINGS
GEB151-1
Cutting procedures
1. DANGER: Keep hands away from cutting area
and the blade. Keep your second hand on
auxiliary handle, or motor housing. If both hands
are holding the saw, they cannot be cut by the blade.
2. Do not reach underneath the workpiece. The guard
cannot protect you from the blade below the
workpiece.
1. Red indicator
2. Button
3. Battery cartridge
4. Star marking
5. Indicator lamps
6. Check button
7. Lever
8. Base
9. Cutting line
10. Lock-off lever
11. Switch trigger
12. Shaft lock
13. Hex wrench
14. Hex bolt
15. Outer flange
16. Saw blade
17. Inner flange
18. Dust nozzle
19. Screw
20. Hose
21. Vacuum cleaner
22. Adjusting screw for 90°
23. Triangular rule
24. Limit mark
25. Brush holder cap
26. Screwdriver
Model DSS500 DSS501
Blade diameter 136 mm
Max. Cutting depth
at 90° 51 mm
at 45° 35 mm
No load speed (min
-1
) 3,600
Overall length 359 mm 364 mm
Net weight 2.3 - 2.6 kg 2.4 - 2.7 kg
Rated voltage D.C. 14.4V D.C. 18V
Battery cartridge
D.C.14.4 V Model BL1415N/BL1430/BL1430B/BL1440/BL1450/BL1460B
D.C.18 V Model
BL1815N/BL1820/BL1820B/BL1830/BL1830B/BL1840/
BL1840B/BL1850/BL1850B/BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF

Makita DSS501 Specifications

General

Blade Diameter	136 mm
Battery Type	Lithium-Ion
Voltage	18 V
Max Cutting Depth at 90°	51 mm
Max Cutting Depth at 45°	35 mm
Weight	2.7 kg
Arbor Size	20 mm
