Makita HM1213C Technical Information

P 8/ 17
Repair
[3] ASSEMBLY/ DISASSEMBLY
[3]-3. Active dynamic vibration absorber (only for HM1213C)
DISASSEMBLING
ASSEMBLING
Fig. 14 Fig. 15
Fig. 16
Fig. 18
Compression
spring 15
Spring guide
Absorber holder portion of
Crank housing complete
Phillips
screwdriver
Slotted screwdriver
Pipe holder
Push Spring guide
(inner part of the
Absorber).
Absorber holder
Spring guide tilts to be hooked
inside Absorber, and the end
of Absorber is removed from
Absorber holder portion of
Crank housing complete.
Disassemble Active dynamic vibration absorber as follows.
Disassemble Active dynamic vibration absorber as illustrated in Figs. 12, 13 and 14.
Assemble Active dynamic vibration absorber as illustrated in Figs. 17 and 18.
Disassemble active dynamic
vibration absorber by levering up
with two Slotted screwdrivers.
Active dynamic
vibration absorber
Pipe holder Pipe holder
O ring 12
O ring 12
O ring 12
O ring 12O ring 24 O ring 24
Compression spring 15 Compression spring 15
Spring guide
Pipe 22
Counter weight Spring guide
Spring guide
Assemble Active dynamic vibration
absorber by pressing while maintaining
its position parallel to Crank housing.
Spring guide
Fig. 17
Spring guide Spring guide
If Spring guide is hooked
in Absorber, push Spring
guide to pop it out from
Pipe holder.
Spring guide protrudes.
Turn and push Pipe holders
as illustrated above.
Pipe holders can be separated.

Makita HM1213C Specifications

General

Input power	1500 W
Impact energy (max)	18.6 J
Vibration level (chiseling)	7 m/s²
Toolholder	18 mm
Impact rate	1900 bpm
Product color	Black, Blue

Weight and Dimensions

Depth	149 mm
Width	576 mm
Height	265 mm
Weight	10800 g
