25
• Have the tool repaired by Makita authorized service center for any failure
on the laser unit.
Replacing fluorescent tube
For model LS0714F, LS0714FL only
CAUTION:
• Always be sure that the tool is switched off and unplugged before
replacing the fluorescent tube.
• Do not apply force, impact or scratch to a fluorescent tube, which can
cause a glass of the fluorescent tube to be broken resulting in a injury to
you or your bystanders.
• Leave the fluorescent tube for a while immediately after a use of it and
then replace it. If not. You may burn yourself.
Remove screws, which secure Lamp Box for the light.
Pull out the Lamp Box keeping pushing lightly the upper position of it as illus-
trated on the left.
Pull out the fluorescent tube and then replace it with Makita original new one.
1. Pull out 2. Push
3. Lamp box 4. Screws
5. Fluorescent tube
1
2
3
4
1
5
002028
