Repair
P 2/ 6
CAUTION: Remove the bit and the battery from the machine for safety before
repair/ maintenance in accordance with the instruction manual!
Spur gear 17
Hammer case complete
[2] LUBRICATION
[1] NECESSARY REPAIRING TOOLS
Fig. 1
Apply Makita grease N. No.2 to the portions designated with the black triangle and Makita grease FA No.2 to the
portions designated with gray triangle to protect parts and product from unusual abrasion.
Description
Vise plate Removing of Hammer case complete
Removing of Hammer case complete
Disassembling of Hammer case complete
Removing of Bit sleeve
Removing of Hammer
Code No.
1R041
1R045 Gear extractor (large)
Center attachment for 1R045
Torque wrench shaft
Ratchet head for 1R223
Pipe 30
Socket 27 -50
Screwdriver Magnetizer
Retaining Ring S and R Pliers Removing Bit sleeve
1R346
1R223
1R224
1R232
1R288
1R291
134844-7
Use for
Item No. Description
Anvil
Steel ball 3 (24 pcs.)
Steel ball 4.8 (2 pcs.)
Outer periphery where the neck of Hammer case contacts
Hole into which the bottom of Anvil is inserted
Whole portion
Portion to lubricate
17
17
19
23
30
19
23
30
25
25
Spindle
DC motor Pinion teeth that engages with Spur gear 17
Removing Steel balls
Lubricant Amount
a little
a little
1g
Makita grease FA.
No.2
Makita grease N. No.2
Makita grease N No. 2
Makita grease FA. No.2
To Next Page
