2 ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: XCU12 XCU14
Overall length
(without guide bar and battery)
357 mm (14″) 408 mm (16″)
Rated voltage D.C. 18 V
Net weight *1 1.1 kg (2.4 lbs)
*2 1.6 - 2.0 kg (3.5 - 4.4 lbs) 1.7 - 2.0 kg (3.7 - 4.4 lbs)
Standard guide bar length 100 mm (4″) 150 mm (6″)
Recommended guide bar length 100 mm (4″) 150 mm (6″)
Applicable saw chain type
(refer to the table below)
80TXL
Sprocket Number of teeth 7
Pitch 0.325″
Chain speed 8.0 m/s
(480 m/min)
(1,570 ft/min)
Chain oil tank volume 55 cm
3
(1.9 oz)
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may dier from country to country.
*1: Weight, without the saw chain, guide bar, guide bar cover, oil and battery cartridge(s).
*2: The lightest and heaviest combination of weight, according to EPTA-Procedure 01/2014. The weight may dier
depending on the attachment(s), including the battery cartridge(s).
Saw chain, guide bar, and sprocket combination
Saw chain type 80TXL
Number of drive links 26 32
Guide bar Guide bar length 100 mm (4″) 150 mm (6″)
Cutting length 111 mm (4-3/8″) 161 mm (6-3/8″)
Part No. 162B84-9 162C41-3
Pitch 0.325″
Gauge 1.1 mm (0.043″)
Type Hard nose bar
Sprocket Number of teeth 7
Pitch 0.325″
WARNING: Do not change the guide bar to a dierent length one. Inappropriate guide bar length may
result in personal injury.
WARNING: Use appropriate combination of the guide bar and saw chain. Otherwise personal injury may
result.
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH / DC18WC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or re.
