1 Stopper pin (for carriage
elevation)
2 Hose (for dust
extraction)
3 Guide fence (upper
fence)
4 Guide fence (lower
fence)
5 Switch trigger 6 Lock-off button 7 Hole for padlock 8 Lid (for wireless unit)
(For XSL08 only)
9 Switch (for laser line) 10 Battery indicator 11 Mode indicator 12 Check button
13 Wireless activation
button
14 Wireless activation lamp 15 Dust bag 16 Bevel angle scale
17 0° adjusting bolt (for
bevel angle)
18 Pointer (for bevel angle) 19 45° adjusting bolt (for
bevel angle)
20 Latch lever (for bevel
angle)
21 Releasing lever (for 48°
bevel angle)
- - - - - -
INSTALLATION
Installing the grip
Screw the threaded shaft of the grip into the turn base.
2
1
► 1. Grip 2. Turn base
