Malaguti Password 250 User Manual

92 09/05
A
PASSWORD 250
FRAME AND RUNNING GEAR
DISASSEMBLY
6
D2
D2
V2
V2
A
V4
C
B
V2
2 ± 20%
V4
10 ± 20%
SEAT
• Release the seat lock with the key and tip it to its open
position.
• Unscrew nuts (D2) and remove the seat, resting it on
a supporting surface with the upholstery upwards.
HELMET COMPARTMENT
• (Remove seat).
• Undo screws (V2) and (V4).
With the helmet compartment fitted, the car-
burettor can be adjusted through opening
(A).
• Remove fuel tank cap (B), remove gasket (C), discon-
necting it from the drip hose, then refit the cap.
Screw the fuel tank cap back on immediate-
ly after removing the gasket.
The helmet compartment is still attached to
the scooter via the seat lock transmission
cable.

Malaguti Password 250 Specifications

General

Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Engine Type	Single cylinder, 4-stroke
Cooling System	Liquid-cooled
Front Brakes	Disc
Rear Brakes	Disc
