Mallory HYFIRE IVC - Gm;Delco Hei Distributor; Gm Hei;Est Distributor - External Ignition Coil; Ford Tfi Systems

4
GM HEI/EST DISTRIBUTOR - EXTERNAL
IGNITION COIL
AND ADAPTER / HARNESS PART NO. 29068
ABCD
IGNITION CONTROL HARNESS
ADAPTER /HARNESS
PART NO. 29068
TO THE
IGNITION
COIL
BOTH OF THE
FACTORY
HARNESS
PLUGS
(ORIGINALLY
CONNECTED
TO THE COIL)
IGNITION
CONTROL
PLUG
LONG BLACK
(–) BATTERY (+)
LONG RED
CHASSIS/FRAME GROUND
(DO NOT CONNECT TO
ENGINE BLOCK)
HYFIRE
®
IGNITION
SYSTEM
®
YELLOW
BLACK
GREEN
RED
YELLOW
BLACK
GREEN
RED
RED AND GREEN
YELLOW AND BLACK
NOTE:
YELLOW/COIL (+)
BLACK/COIL (–)
SMALL GREEN AND BLACK
WIRES – NOT USED
FIGURE 6
GM/DELCO HEI DISTRIBUTOR
(WITH COIL MOUNTED INSIDE DISTRIBUTOR CAP)
ADAPTER / HARNESS
PART NO. 29042
ABCD
PINK OR RED
GM/DELCO HEI DISTRIBUTOR
WITH COIL MOUNTED INSIDE
DISTRIBUTOR CAP
MALLORY 8MM SUPPRE
DISTRIBUTOR
PLUG
NOTE: LEAVE TACH PLUG, IF THERE IS ONE,
PLUGGED INTO THE DISTRIBUTOR CAP
ADAPTER / HARNESS
PART NO. 29042
GREEN
RED
BAT
PLUG
BLACK
TO ENGINE
GROUND
BROWN
YELLOW
IGNITION CONTROL
HARNESS
NOTE: MOST AFTERMARKET REPLACEMENT IGNITION MODULES WILL NOT
TRIGGER THE HYFIRE
®
IGNITION SYSTEM. THE BEST TYPE TO USE IS AN
ORIGINAL GM/DELCO IGNITION MODULE.
TO VEHICLE HARNESS
IGNITION
CONTROL
PLUG
LONG BLACK
(–) BATTERY (+)
LONG RED
CHASSIS/FRAME GROUND
(DO NOT CONNECT TO
ENGINE BLOCK)
SMALL GREEN AND BLACK
WIRES – NOT USED
HYFIRE
®
IGNITION
SYSTEM
®
FIGURE 5
FORD TFI SYSTEMS
ADAPTER / HARNESS
PART NO. 29062
ABCD
IGNITION
CONTROL
PLUG
LONG BLACK
(–) BATTERY (+)
LONG RED
CHASSIS/FRAME GROUND
(DO NOT CONNECT TO
ENGINE BLOCK)
HYFIRE
®
IGNITION
SYSTEM
®
YELLOW
BLACK
GREEN
RED
YELLOW
BLACK
GREEN
RED
NOTE:
YELLOW/COIL (+)
BLACK/COIL (–)
ADAPTER /HARNESS
PART NO. 29062
TO THE
IGNITION
COIL
YELLOW
GREEN
RED
BLACK
FACTORY
HARNESS
PLUG
(ORIGINALLY
CONNECTED
TO THE COIL)
SMALL GREEN AND BLACK
WIRES – NOT USED
IGNITION CONTROL HARNESS
FIGURE 7
