GENERAL INFORMATION
1 - INTRODUCTION OF THE PRODUCT COMPONENTS
1.1 - RCD MODELS
Socket Equipped Models Tethered Cable Models
3
2
1
5
6
9
4
4
8
5
3
2
1
6
7
10
9 8
7
en
Socket Models
1- Information Display
2- RFID Card Reader
3- Status indicator LED
4- MID Meter Display
5- Socket Outlet
6- Product Label
7- Charging station
communication cable gland nut
8- Charging station
communication cable gland nut
9- Charging station supply inlet
gland nut
en
Tethered Cable Models
1- Information Display
2- RFID Card Reader
3- Status indicator LED
4- MID Meter Display
5- Dummy Socket
6- Charging Plug
7- Product Label
8- Charging cable
9- Charging station
communication cable gland nut
10- Charging station supply inlet
gland nut
